Gel Battery Series
By combining the newly developed Gel electrolyte, GEL series battery(2V and 12V, The capacity ranges from 33AH to 3000AH) is long cycle life and stable performance at high and low temperature surrounding. The acid stratification is highly reduced by adding Gel. GEL series is suited for all kinds of ranges especially for renewable energy systems, such as solar power and wind power system.
General feature & Advantage
- Valve sealed design, no free electrolyte, and maintenance free
- Designed floating service life: 3~15 years @ 25C/68F
- Wide operating temperature range from -15C to 55C
- Gel electrolyte eliminates the acid stratification and prolongs cycle life
- Low self-discharge rate.
- Capacity range: 33Ah to 3000Ah
- Voltage range: 2V/12V
- Cycle Life: 30% DOD: 1700 cycles, 50% DOD: 800 cycles, 100% DOD: 350 cycles
- Superior deep cycle design
- Very long life in deep cycle applications
Application
- UPS Systems
- Portable Equipment
- Solar System
- Wind System
- Renewable Energy Systems
- Telecom Systems
- Electric Wheelchair
- Etc
GEL Battery Series |
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage | Rated Capacity | Terminal | Battery Dimension（mm） | Weight( KGS) | Spec | |||
| (V) | (AH) | Length | Width | Height | Total Height | ±3% | |||
| GEL12-33 | 12V | 33 AH | L3/M6 | 196 | 131 | 161 | 168 | 10.6 KG | View |
| GEL12-38 | 12V | 38 AH | L4/M6 | 196 | 166 | 176 | 176 | 12.5 KG | View |
| GEL12-40 | 12V | 40 AH | L4/M6 | 196 | 166 | 176 | 176 | 13.2 KG | View |
| GEL12-55 | 12V | 55 AH | L5/M6 | 229 | 137 | 205 | 210 | 17.2 KG | View |
| GEL12-65 | 12V | 65 AH | M6 | 350 | 169 | 179 | 179 | 20.4 KG | View |
| GEL12-75 | 12V | 75 AH | L5/M6 | 260 | 169 | 213 | 217 | 22.0 KG | View |
| GEL12-90 | 12V | 90 AH | M6/M8 | 306 | 168 | 211 | 215 | 28.2 KG | View |
| GEL12-100 | 12V | 100 AH | M8 | 328 | 172 | 218 | 222 | 30.2 KG | View |
| GEL12-120 | 12V | 120 AH | M8 | 406 | 173 | 237 | 237 | 35.5 KG | View |
| GEL12-150 | 12V | 150 AH | M8 | 484 | 170 | 240 | 240 | 43.0 KG | View |
| GEL12-200 | 12V | 200 AH | M8 | 522 | 240 | 218 | 222 | 60.5 KG | View |
| GEL12-250 | 12V | 250 AH | M8 | 520 | 269 | 219 | 223 | 72.5 KG | View |
| GEL2-200 | 2V | 200 AH | M8 | 173 | 111 | 335 | 365 | 12.5 KG | View |
| GEL2-300 | 2V | 300 AH | M8 | 171 | 151 | 340 | 365 | 18.8 KG | View |
| GEL2-400 | 2V | 400 AH | M8 | 210 | 175 | 336 | 365 | 24.5 KG | View |
| GEL2-500 | 2V | 500 AH | M8 | 240 | 172 | 338 | 365 | 29.7 KG | View |
| GEL2-600 | 2V | 600 AH | M8 | 301 | 175.5 | 340 | 365 | 36.5 KG | View |
| GEL2-800 | 2V | 800 AH | M8 | 409 | 175 | 340 | 365 | 48 KG | View |
| GEL2-1000 | 2V | 1000 AH | M8 | 475 | 175 | 337 | 364 | 60 KG | View |
| GEL2-1200 | 2V | 1200 AH | M8 | 475 | 175 | 337 | 364 | 62.5 KG | View |
| GEL2-1500 | 2V | 1500 AH | M8 | 353 | 335 | 328 | 347 | 85 KG | View |
| GEL2-2000 | 2V | 2000 AH | M8 | 490 | 350 | 344 | 383 | 129 KG | View |
| GEL2-3000 | 2V | 3000 AH | M8 | 712 | 353 | 341 | 382 | 171 KG | View |
